libcurl HTTP/2 Streaming Upload Use-After-Free Flaw Exposes Client Applications to Memory Corruption

A high-severity memory safety vulnerability in the ubiquitous libcurl networking library (tracked as CVE-2026-92392) allowed malicious HTTP/2 servers to trigger a heap use-after-free condition on client applications performing streaming uploads. Documented in coordinated public disclosure via HackerOne (Report #4030333) by security researcher onn4a, the defect stems from complex asynchronous lifecycle desynchronization between paused client upload buffers, multiplexed nghttp2 stream cancellation frames, and connection pool retry logic.

The HTTP/2 Streaming Upload Architecture in libcurl

Modern implementations of HTTP/2 multiplex multiple independent request/response streams over a single underlying TCP/TLS connection. In libcurl, this multiplexing is orchestrated by the HTTP/2 connection filter (lib/cf-h2.c), working in tandem with the third-party framing library nghttp2. Each transfer is represented by a struct Curl_easy handle, while stream-specific state (such as stream identifiers, receive windows, and send buffers) is maintained within struct cf_h2_stream.

When an application uploads a file via curl -T <file>, the upload progresses through the multi-interface state machine. Data flows from the client read callback into the request buffer (req.sendbuf). From there, the connection filter feeds data into nghttp2_submit_request(), attaching the struct Curl_easy pointer (data) as stream user data so that subsequent framing callbacks know which transfer is generating or receiving traffic.

In high-throughput environments, backpressure is managed through HTTP/2 flow control windows. If the remote server stops granting stream or connection window updates (or grants a window of 0), libcurl's upload stalls. The read callback returns NGHTTP2_ERR_DEFERRED, parking leftover unsent request bytes inside req.sendbuf while waiting for the peer to dispatch WINDOW_UPDATE frames.

Root Cause: Asynchronous Lifecycle Desynchronization

The vulnerability manifests when a malicious or non-compliant HTTP/2 server exploits the stall condition to force an asynchronous connection retry while un-transmitted bytes remain buffered.

The researcher mapped the entire control flow across six distinct phases, illustrating how two conflicting pointers are stored in nghttp2:

PHASE 1: Upload Starts
Curl_req_send()                                 request.c:380    request head + body -> req.sendbuf
└─ req_flush() -> cf_h2_send()                  http2.c:2197     no stream yet
   └─ h2_submit()                               http2.c:2062
      ├─ http2_data_setup()                     http2.c:361      streams[mid] created
      └─ nghttp2_submit_request(..., data)      http2.c:2133     stream 1 -> data  <-- Pointer #1 stored

PHASE 2: Upload Stalls (Server Grants 0 Flow-Control Window)
multistate_performing() -> Curl_sendrecv()      multi.c:2029 -> transfer.c:354
└─ sendrecv_ul() -> Curl_req_send_more()        transfer.c:340 -> request.c:458
   ├─ add_from_client()                         request.c:351    read file -> req.sendbuf (64 KB)
   └─ req_flush() -> cf_h2_send()               http2.c:2197
      └─ cf_h2_body_send()                                       -> stream->sendbuf
         └─ req_body_read_callback()            http2.c:1577     window is 0 -> NGHTTP2_ERR_DEFERRED
   => Leftover bytes remain parked in req.sendbuf

PHASE 3: Server Sends HEADERS(200) + RST_STREAM(HTTP_1_1_REQUIRED)
multistate_performing()                         multi.c:2029
├─ sendrecv_dl() -> xfer_recv_resp()            transfer.c:269
│  └─ cf_h2_recv() -> h2_progress_ingress()     http2.c:1972
│     └─ nghttp2_session_mem_recv()                              parses RST_STREAM
│        └─ on_stream_close()                   http2.c:1298
│           ├─ stream->closed = TRUE            http2.c:1333
│           └─ set_stream_user_data(0)          http2.c:1346     stream 1 pointer cleared
├─ if(result == CURLE_HTTP2_STREAM && Curl_h2_http_1_1_error())
│     retry = TRUE; follow = FOLLOW_RETRY       multi.c:2087
│
│  PHASE 4: Wrap-Up & Accidental Re-Submission
├─ multi_done(data, CURLE_OK, premature=FALSE)  multi.c:2130
│  ├─ cf_cntrl_all(CF_CTRL_DATA_DONE)           cfilters.c:448
│  │  └─ http2_data_done()                      http2.c:416
│  │     └─ hash_remove(streams, mid)           http2.c:447      <-- Filter forgets transfer
│  ├─ result = Curl_req_done(aborted=FALSE)     multi.c:754 -> request.c:102
│  │  └─ req_flush() -> xfer_send()             request.c:298    req.sendbuf not empty!
│  │     └─ cf_h2_send()                        http2.c:2197     stream == NULL -> interpreted as "new request"
│  │        └─ h2_submit()                      http2.c:2062
│  │           └─ nghttp2_submit_request(..., data)              stream 3 -> data  <-- Pointer #2 stored!
│  └─ multi_done_locked()                       multi.c:632
│     └─ Curl_cpool_conn_now_idle()                              conn back in pool, stream 3 still -> data
└─ result = multi_follow(FOLLOW_RETRY)          multi.c:2132     retry on new HTTP/1.1 connection

PHASE 5: Retry Finishes, Easy Handle Freed
del_per_transfer()                              src/tool_operate.c:240
└─ curl_easy_cleanup() -> Curl_close()          url.c:197
   └─ free(data)                                url.c:303        <-- Pointer #2 now dangling!

PHASE 6: Connection Pool Teardown Triggers UAF
Curl_cpool_destroy() -> cf_h2_shutdown()        http2.c:2559
└─ h2_progress_ingress()                        http2.c:1865
   └─ nghttp2_session_mem_recv()                                 server sends HEADERS for stream 3
      └─ on_begin_headers()                     http2.c:1355
         ├─ data_s = get_stream_user_data(3)   http2.c:1364     returns freed pointer!
         └─ H2_STREAM_CTX(ctx, data_s)         http2.c:1373     dereferences data_s->mid  <-- CRASH / UAF

Exploitation Mechanics & AddressSanitizer Crash Walkthrough

To demonstrate the vulnerability end-to-end, researcher onn4a provided a malicious Python server (evil-server.py) that accepts TLS connections on port 19170. When an ASan-instrumented build of curl 8.22.0 uploads a document:

# Run curl with AddressSanitizer against the test server:
./src/curl --insecure -T ./sample_docs.md https://127.0.0.1:19170/x

The server intentionally delays the flow-control window until req.sendbuf is saturated with 64 KB of file data, then dispatches an RST_STREAM frame with error code 0xd (HTTP_1_1_REQUIRED). The connection filter cleanly clears pointer #1. But when Curl_req_done() executes during wrap-up, the un-cleared buffer forces a spurious new request submission on stream 3, storing pointer #2.

When the connection pool is cleaned up during shutdown, AddressSanitizer intercepts the illegal memory access:

=================================================================
==54128==ERROR: AddressSanitizer: heap-use-after-free on address 0x50c000000100 at pc 0x0000005a1e8c bp 0x7fff89ab10e0 sp 0x7fff89ab10d8
READ of size 8 at 0x50c000000100 thread T0
    #0 0x5a1e8b in on_begin_headers lib/cf-h2.c:1373:42
    #1 0x7f55b92e21b2 in nghttp2_session_on_header_received lib/nghttp2_session.c:4821
    #2 0x7f55b92db943 in nghttp2_session_mem_recv lib/nghttp2_session.c:6120
    #3 0x5a3e14 in h2_process_pending_input lib/cf-h2.c:487:14
    #4 0x5a3962 in h2_progress_ingress lib/cf-h2.c:1865:12
    #5 0x5a5611 in cf_h2_shutdown lib/cf-h2.c:2559:5
    #6 0x582419 in Curl_conn_shutdown lib/cfilters.c:225:10
    #7 0x5776d2 in Curl_cpool_destroy lib/conncache.c:247:7
    #8 0x57291a in curl_share_cleanup lib/curl_share.c:370:7
    #9 0x502b41 in main src/tool_main.c:329

0x50c000000100 is located 0 bytes inside of 5440-byte region [0x50c000000100,0x50c000001640)
freed by thread T0 here:
    #0 0x4981ad in free
    #1 0x57488f in Curl_close lib/url.c:303:5
    #2 0x573bb2 in curl_easy_cleanup lib/easy.c:924:3
    #3 0x5079a4 in del_per_transfer src/tool_operate.c:240:5

Ecosystem Impact: System Daemons, Cloud SDKs & Containers

Because libcurl is the default HTTP client engine across the computing industry, memory corruption flaws in its transfer pipeline have vast consequences:

Remediation & Upstream Patch Implementation

The curl development team resolved the defect by modifying the transfer wrap-up logic in lib/transfer.c. Whenever an HTTP/2 transfer terminates due to an RST_STREAM or stream failure, libcurl explicitly invokes Curl_req_abort_sending():

// Upstream patch in lib/transfer.c:
if(result != CURLE_AGAIN) {
  /* Ensure unsent request buffers are purged before handling retries */
  Curl_req_abort_sending(data);
  goto out;
}

By purging req.sendbuf when the error occurs, subsequent invocations of Curl_req_done() encounter an empty buffer, preventing the spurious submission of stream 3 and ensuring no dangling references remain in nghttp2 user data structures.
